MLN-2


Three-Axis Coarse/Fine Micromanipulator with Rotation Mechanism (Tilting Base)

- Special Order - Pricing Available Upon Request
Narishige's MLN-2 is a three axis coarse/fine micromanipulator with a tilting stand attachment for improved stability. In addition to main features such as a fine movement unit operating in the same direction as the microelectrode, a rotation mechanism and pivot/tilt capabilities, the MLN-330 is mounted on a tilting stand. This gives better stability than simple bar attachment. The fine movement unit is mounted on the Z-axis and enables fine adjustment of height. The tilting stand features a foldaway angle adjustment pole, so as not to interfere with operation.

*Changing the H-1 that attaches the manipulator to optional oil hydraulic micromanipulator such as MO-10 enables remote controlled X axis fine movement.

Specification
Accessories H-1 Electrode Holder, Dedicated electrode holder,
Allen Wrench, Mounting Screw, Flat Washer, Clamp Rod
Movement range Coarse X38mm, Y25mm, Z30mm
With tension adjustment mechanism
Fine X35mm, Full rotation of knob 250um
Minimum graduation 10um
With rotation mechanism, With pivot and tilt mechanism
With tilting stand, With height adjustment unit
Dimension Main body W110 x D90 x H170mm
Tilting stand W130 x D150 x H45mm
Weight 4.2kg (includes tilting stand)


*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered.
