Narishige's MM-89 is a the most popular coarse motor drive manipulator that enables remote controlled movement of a pipette into a microscope observation field. The bigger the microscope, the more difficult manual control becomes; remote control is the mainstream alternative. Control is easy, with the joystick right at the operator's hand, and a return mechanism facilitates pipette exchange.

Specification

Accessories included		Power Supply Cable, Allen Wrench
Movement range	Coarse	X22mm, Y22mm, Z22mm
Power source		AC100V(+-5%), AC120V(+-5%), AC220V(+-5%), AC240V(+-5%)
Power consumption		Approx. 15W
Dimensions/Weight	Power supply	W125 x D105 x H85mm, 1.5kg
	Control unit	W55 x D75 x H120mm, 0.3kg
	Drive unit	W63 x D102 x H104mm, 0.5kg

† These are our list prices. If you are paying with an Institutional Purchase Order or by check, you qualify for a 7.5% discount. Click here to change your payment method and see the lower prices.

MM-89

Three-Axis Coarse DC Motor Drive Micromanipulator
