| Item Number |
Description |
Price† |
Qty |
->Cart |
| BP-1 |
Base Plate |
$0.00
|
| TSB-1 |
X-Y Base |
$3,945.95
|
| TSP-1 |
Base Plate |
$0.00
|
| TSP-4 |
Stage Plate |
$2,216.22
|
| TSP-5 |
Mounting Rack |
$232.43
|
| TSP-6 |
Mounting Plate |
$118.92
|
| TSP-9 |
Stage Plate |
$2,594.59
|
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
Direct-Drive Micromanipulators |
Ball joint w/ adjustable clamp C-1
| |
BC-3:
$778.38
†
- Special Order To Be Discontinued
|
|
The compact, adjustable clamp C-1 comes mounted on a ball joint, and can be used for various assisting purposes. The ball joint mounting enhances ease of use by allowing one to change the angle relative to the mounting bar.
*Mounting bar sold separately.
*Use GJ-1 magnetic stand or equivalent equipment to attach this model.
When ordering, please indicate if the unit will be mounted on the right or left side as there are two different versions of the BC-3 clamp... or get one of each!
Specifications | Accessories included | XY Control Knob, Allen Wrench | | Movement range: | Coarse | Z19mm | | Fine | X15mm, Y6mm | | Dimensions/Weight | W80 x D46 x H96mm, 250g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Ball joint w/ adjustable clamp C-2
| |
BC-4:
$870.27
†
- Group II Special Order
|
|
The compact, adjustable clamp C-2 comes mounted on a ball joint, and can be used for various assisting purposes. The ball joint mounting enhances ease of use by allowing one to change the angle relative to the mounting bar.
*Mounting bar sold separately.
*Use GJ-1 magnetic stand or equivalent equipment to attach this model.
When ordering, please indicate if the unit will be mounted on the right or left side as there are two different versions of the BC-4 clamp... or get one of each!
|
| BC-4L
| BC-4R
|
Specifications | Accessories included | XY Control Knob, Allen Wrench | | Movement range: | Coarse | Z24mm | | Fine | X15mm, Y6mm | | Dimensions/Weight | W80 x D46 x H96mm, 300g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Adjustable Clamp (R/L)
| |
C-1:
$772.97
†
- Group II Special Order
|
|
Narsishige's C-1 clamp is an economical alternative to a micromanipulator. It is very compact and equipped with a three-dimensional position adjustment. It can be attached using a 6mm bar.
Specifications
| Accessories included | X-Y Control Knob
ø6 × 120mm Threaded Bar
Allen Wrench |
|---|
| Movement range | Coarse | Z19mm |
|---|
| Fine | X15mm, Y6mm |
|---|
| Dimensions/Weight | W65 × D47 × H65mm, 130g |
|---|
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Adjustable Clamp (R/L)
| |
C-2:
$778.38
†
- Group II Special Order
|
|
Narsishige's C-2 clamp is an economical alternative to a micromanipulator. It is very compact and equipped with a three-dimensional position adjustment. It can be attached using a 6mm bar.
Specifications
| Accessories included | X-Y Control Knob
ø6 × 120mm Threaded Bar
Allen Wrench |
|---|
| Movement range | Coarse | Z24mm |
|---|
| Fine | X15mm, Y6mm |
|---|
| Dimensions/Weight | W65 × D47 × H73mm, 190g |
|---|
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Microinjector Accessories
|
|
| Item Number |
Description |
Price† |
Qty |
->Cart |
| SA-8 |
Semi-chronic Head Holder (for Rats) |
$0.00
|
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
Kleindiek Ultra-precise Force Measurement System
| |
FMS-LS:
$15,330.90
†
- Approx. 30 days
|
|
The Force measurement system is an accessory to the micromanipulator that allows you to perform measurements and nanoindentation. The attachment is connected to a controller which displays force feedback, and plays the resonance frequencies of your materials on a loudspeaker.
The system consists of a force sensor with integrated pipette holder, control module with preamplifier and a loudspeaker, PC software, a power supply, and an operator's handbook.
Applications - Measurement of elastic parameters of cells, Young's modulus, spring constants of MEMS and resonance frequencies
- Nanoindentation
Specifications - Resolution: sub-µN
- Force range: up to 10 mN
- Output: +/- 10 V
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Kleindiek Ultra-precise Piezo-motor Micromanipulator System
| |
Quantity Pricing
$17,295.14
† - Regular price.
$16,754.59
† - 2 or more.
$16,214.05
† - 3 or more.
$15,673.51
† - 4 or more.
|
|
Top Features:
- Easy setup: no cumbersome brackets to fiddle around with; just place the sturdy magnetic micromanipulator onto your microscope stage and start injecting! The NanoControl box and Joypad/Joystick/Cube sit next to the microscope for easy access and ergonomic ease.
- Virtually impervious to vibration
- Very low drift (1 nm/min) (yes, that is 1 nanometer!)
- Sub-nanometer resolution (0.25nm)
- Extensive working range (100cm3)
- Integrated coarse and fine movement in one unit
- High operating velocity (up to 10mm/sec!)
The Kleindiek Nanotechnik MM3A Micromanipulator is a convenient, amazingly precise, and effective solution for patch clamp experiments, in-vitro fertilization (IVF / ICSI), transgenic construction, embryo manipulation, chromosomal dissection, and any types of work that require ultra-precise movement control. It features the ability to move very quickly to the desired location, while maintaining a precision of less than a nanometer! This is over 20 times more precise than any of the Narishige micromanipulators that we offer, and over 40 times more precise than Eppendorf TransferMan® NK 2, InjectMan® NI 2 and PatchMan® systems. If you want incredible precision and stability without sacrificing your working range and operating velocity, this is the micro-manipulator for you!
The MM3A can be maneuvered very easily in all axes using the joystick control. This ergonomic intuitive user interface combined with a wide range of movement speeds makes the Kleindiek Nanotechnik MM3A ideal for microinjection and micro-dissection.
The MM3A is also ideal for patch clamp experiments in the neurobiology lab. It is literally the best micromanipulator for electrophysiology because it is easy to maneuver quickly into place, offers nanometer-level precision when making the fine adjustments to contact the neuron's cell membrane, and yields a stable signal throughout the experiment because it has virtually no drift (unlike fine hydraulic micromanipulators that drift in response to subtle temperature changes).
Click to pop up a comparison chart showing how much more precise, more compact, faster and lighter the MM3A is compared with Eppendorf TransferMan® NK 2, InjectMan® NI 2 and PatchMan® systems and how it compares with our various Narishige alternatives.
Controlling the MM3A: Below is a diagram of how the controls of the MM3A work. The NanoController and the Joypad (top two devices shown in the diagram) are included with the MM3A. Under the standard factory settings, the buttons on the joypad are used to move in coarse mode. The two joysticks can control in either fine or coarse mode depending on your speed selection. Additionally, you can set a home / park position that the micromanipulator can move quickly to and from when performing multiple injections.
For easier high-precision control (such as positioning a patch clamp pipette), we recommend the Cube, a manual control device with three high-resolution vernier dials (bottom device shown on the diagram). It gives you highly responsive, intuitive, linear movement control. It connects directly to the NanoControl control electronics in addition to your choice of joystick.
The course movement range is several centimeters and, once near your target, the standard fine working range of the MM3A is 20 µm. If you want a larger fine mode working range, add the Booster option. This module for the NanoControl control electronics doubles the fine mode working range.
Specifications:
Dimensions
| 57.1mm x 20.4mm x 25.4mm
| Weight
| 45g
| Movement Range
| Travel range in the linear axis - 12mm
Travel range in the rotational axes - 240°
| Operating Velocity
| Up to 10mm/sec
| Precision
| 0.25nm resolution
| Accessories Included
| - Pipette holder for 1mm or 2mm pipettes
- Magnetic mounting foot
- Microscope stage adapter plate
- Connectors for pipette pressurization and headstage
- NanoControl control electronics with joypad and software for Windows 98/NT/ME/2K/XP.
|
Check out the link below for more details, and a video of the MM3A-LS in action on Kleindiek's website: http://www.nanotechnik.com/mm3a-ls.html
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Manipulator for experiments using stereo microscopes.
| |
MWS-1:
$1,027.03
†
- Discontinued
|
|
Narishige's MWS-1 is a manual manipulator developed for experimental tasks under low magnifications using a stereo microscope. An adaptor attachment is employed according to the size of the stand with which the illumination equipment is integrated. Its compact size makes it possible to place the unit close to the specimen. A pipette rotation and return mechanism is included to simplify pipette exchange.
*For attachment to the microscope, a suitable adaptor is required (sold separately).
Specification| Accessories included | UT-2 Universal Joint, H-7 Pipette Holder, Allen Wrench | | Movement range | Coarse | X15mm, Y15mm, Z15mm | | Dimensions/Weight | W105 x D115 x H110mm, 300g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Kleindiek Ultra-precise Lift-Out Shuttle
| |
SY-LOS:
$58,372.97
†
- Approx. 30 days
|
|
The Lift-Out Shuttle is a super-fast, dedicated lift-out solution for preparing samples for ex-situ electron microscopy. It features a microgripper, a four-axis substage, and a small CCD camera at surface level that allows for fast approach.
The system is comprised of a four-axis substage mounted on an ultra-compact platform. A microgripper is mounted above the substage to facilitate the lift-out. The stage is manipulated to position the pre-cut sample under the microgripper. After that, the microgripper clamps onto the sample and holds it gently, but firmly enough that the sample can be freed from the bulk material by simply dropping the stage down and out of the way. Once isolated, the sample is brought in contact with SEM-compatible glue on a TEM grid, and cured with an ion beam.
To see a video of this process in action, please follow the link to Kleindiek's website: http://www.nanotechnik.com/lift-out-shuttle.html
The system includes control electronics, a joypad, a microgripper, and an operator's handbook.
Specifications:
- Substage on load-lock compatible platform
- Maximum specimen size: 30mm
- Travel: X and Y = 10mm
Travel: Z = 3mm
Travel: R = 360°(unlimited) - Speed: up to 1mm/s
- Resolution: <0.5nm
- Cartesian movement
- No backlash or reversal play
- Simple load-lock solutions for most SEM and FIB tools
- Virtually insusceptible to vibrations
Microgripper
- High-resolution gripper for transport and assembly of micro-sized objects
- Gripping area: (5 to 10 µm)
- Resolution: 20nm
- Gripping force: 5 to 5000 µN (variable)
- Maximum span range: 20 to 40 µm
SemCam
- Small camera at sample surface level
- Allows fast approach
- Includes monitor and LED illumination
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Muscle Fixing Apparatus
| |
A-2:
$1,189.19
†
- Discontinued
|
|
Narishige's A-2 Muscle Fixing Apparatus facilitates insertion of a microelectrode into muscle or nerve fibers by gripping both ends of the muscle or nerve fiber and holding it under tension by stretching both ends mildly.
Note that Narishige's A-2 is a component of Narishige's A-3 and needs rest of the components of A-3 for using it. If you want to use A-2 independently, we recommend that you attach it to the stand using Narishige's X-Block.
Specifications | Movement range | Fine | Y30mm | | Dimensions/Weight | W160 x D130 x H40mm, 500g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Patch Clamp Headstage Holder: Adapter (for Axon)
| |
AP-12A:
$129.73
†
- Ships in 1-5 days
|
|
Narishige's AP-12A adapter is used for connecting Axon patch amplifiers, chiefly to B-9 (attached to MHW-3).
Heka Type: AP-12L
Nihon Koden Type: AP-12N
Specifications | Dimensions/Weight | AP-12A | W58 x D36 x H12mm, 18g | | AP-12L | W65 x D39 x H9mm, 5g | | AP-12N | W40 x D21 x H9mm, 6g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Patch Clamp Headstage Holder: Adapter (for List)
| |
AP-12L:
$129.73
†
- Discontinued
|
|
Narishige's AP-12L adapter is used for connecting Line patch amplifiers, chiefly to B-9 (attached to MHW-3).
Axon Type: AP-12A
Nihon Koden Type: AP-12N
Specifications | Dimensions/Weight | AP-12A | W58 x D36 x H9mm, 12g | | AP-12L | W65 x D39 x H9mm, 5g | | AP-12N | W40 x D21 x H9mm, 6g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Patch Clamp Headstage Holder: Adapter (for Nihon Koden)
| |
AP-12N:
$129.73
†
- Discontinued
|
|
Narishige's AP-12N adapter is used for connecting Nihon Koden patch amplifiers, chiefly to B-9 (attached to MHW-3).
This adapter is used for connecting leading brands of patch amplifiers, chiefly to B-9 (attached to MHW-3).
Axon Type: AP-12A
Heka Type: AP-12L
Specifications | Dimensions/Weight | AP-12A | W58 x D36 x H9mm, 12g | | AP-12L | W65 x D39 x H9mm, 5g | | AP-12N | W40 x D21 x H9mm, 6g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Patch Clamp Headstage Holder: Adapter (Block-equipped for B-9)
| |
AP-13-2:
$167.57
†
- Ships in 1-5 days
|
|
Narishige's AP-13-2 block equipped adapter is used for connecting the Axopatch 200B amplifier to Narishige products.
*Type 2: Block-equipped for B-9 (Equivalent to AP-12)
Specifications | Accessories included | Allen Wrench | | Dimensions/Weight | AP-13-2 | W64 x D26 x H15mm, 28g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Patch Clamp Headstage Holder: Adapter (Block-equipped for powerful universal joint)
| |
AP-13-3:
$167.57
†
- Ships in 1-5 days
|
|
Narishige's AP-13-3 block equipped adapter is used for connecting the Axopatch 200B amplifier to Narishige products.
*Type 3: Block-equipped type for powerful universal joint (Equivalent to AP-14)
Specifications | Accessories included | Allen Wrench | | Dimensions/Weight | AP-13-3 | W64 x D26 x H12mm, 27g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Axon Patch Clamp Headstage Holder: Adapter
| |
AP-14A:
$129.73
†
- Ships in 1-5 days
|
|
Narishige's AP-14A adapters are used for connecting Axon patch amplifiers to the powerful universal joint.
*Attachable Solid Universal Joints: UST-1, UST-2, UST-3 etc.
See the Patch Clamp Headstage Holder Summary Table for overview of all combinations.
Specifications | Dimensions/Weight | AP-14A | W58 x D36 x H9mm, 15g | | AP-14L | W65 x D39 x H9mm, 15g | | AP-14N | W40 x D21 x H9mm, 6g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Line Patch Clamp Headstage Holder Adapter
| |
AP-14L:
$129.73
†
- Discontinued
|
|
Narishige's AP-14L adpaters are used for connecting Line's patch amplifiers to the powerful universal joint.
*Attachable Solid Universal Joints: UST-1, UST-2, UST-3 etc.
See the Patch Clamp Headstage Holder Summary Table for overview of all combinations.
Specifications | Dimensions/Weight | AP-14A | W58 x D36 x H9mm, 12g | | AP-14L | W65 x D39 x H9mm, 15g | | AP-14N | W40 x D21 x H9mm, 6g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Nihon Koden Patch Clamp Headstage Holder Adapter
| |
AP-14N:
$129.73
†
- Discontinued
|
|
Narishige's AP-14N adapters are used for connecting Nihon Koden's patch amplifiers to the powerful universal joint.
*Attachable Solid Universal Joints: UST-1, UST-2, UST-3 etc.
See the Patch Clamp Headstage Holder Summary Table for overview of all combinations.
Specifications | Dimensions/Weight | AP-14A | W58 x D36 x H9mm, 12g | | AP-14L | W65 x D39 x H9mm, 15g | | AP-14N | W40 x D21 x H9mm, 6g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Patch Clamp Headstage Holder (with Ball Joint)
| |
APB-13:
$378.38
†
- Ships in 1-5 days
|
|
This is a headstage adapter to attach a variety of electrophysiology headstages to almost any of our micromanipulators. Axon Multi Clamp 700B (CV-7B) and Heka EPC-10 are examples. With the APB-13 these can be mounted via a standard 7 mm diameter mounting bar. The headstage angle can be adjusted and locked via the ball joint.
For the EPC-10, the headstage mounting bracket (a plate with dovetail) is provided by HEKA.
Specifications | Accessories included | Mounting Screw & Hex Wrench | | Dimensions/Weight | W82 x D26 x H57mm, 70g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Curved Glass Bottom Chamber Dish For Immersion Lens
| |
CK-1:
$410.81
†
- Ships in 1-5 days
|
|
Narishige's CK-1 is a curved glass bottom chamber dish for an immersion lens. For sophisticated observation, the use of a glass bottom dish is essential in connection with the polarization ratio. While disposable glass bottom dishes are already available, we have developed a chamber-type glass bottom dish that enables more sophisticated observation.
The gently-curved chamber minimizes bulges in fluid level and controls polarization. It also stabilizes the fluid surface and facilitates the use of an immersion lens. A commercially available cover glass can be inserted at the bottom that is easy to clean and sterilize, and permits reuse instead of discarding it after use.

Accessories included: Cover Glass (100 pcs), Clamp Jig, Silicone Grease, Silicone Rubber Gasket
Dimensions/Weight: W60 x D60 x H8mm, 55g
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Ear Bar for SN Series
| |
EB-1:
$416.22
†
- Special Order
|
|
Narisihige's EB-1 is a standard ear (in a pair) bar for use with the SN series stereotaxic instruments.
Specifications
| Length/Weight | L115mm, 80g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Hollow Ear Bar for SN Series
| |
EB-2A:
$541.62
†
- Special Order. Limited Stock. To Be Discontinued
|
|
Narisihige's EB-2A is a special ear bar for the SN series. The A-type is hollow inside and can be used for auditory experiments.
Please also consider the following ear bars:
EB-2B Special Ear Bar (non-ruputure type, in a pair)
EB-2C Special Rat Ear Bar (in a pair)
EB-2D Special Guinea Pig Ear Bar (in a pair)
Specifications
| Length/Weight | L140mm, 95g (per pair) |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Nonrupture Ear Bar
| |
EB-2B:
$491.89
†
- Special Order. Limited Stock. To Be Discontinued
|
|
Narishige's EB-2B is a special ear bar for the SN series. The B-type has a special design tip which does not hurt the soft ear opening.
Please also consider the following ear bars:
EB-2A Special Ear Bar (hollow type, in a pair)
EB-2C Special Rat Ear Bar (in a pair)
EB-2D Special Guinea Pig Ear Bar (in a pair)
Specifications
| Length/Weight | L140mm, 95g (per pair) |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Rat Ear Bar
| |
EB-2C:
$541.62
†
- Special Order. Limited Stock. To Be Discontinued
|
|
Narishige's EB-2C is a special ear bar for the SN series. The C-type is used for rats, in combination with adaptor RA-4.
Please also consider the following ear bars:
EB-2A Special Ear Bar (hollow type, in a pair)
EB-2B Special Ear Bar (non-ruputure type, in a pair)
EB-2D Special Guinea Pig Ear Bar (in a pair)
Specification
| Length/Weight | L140mm, 95g (per pair) |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Guinea Pig Ear Bar
| |
EB-2D:
$541.62
†
- Special Order. Limited Stock. To Be Discontinued
|
|
Narishige's EB-2D is a special ear bar for the SN series. The D-type is for guinea pigs and used in combination with adaptor RA-3.
Please also consider the following ear bars:
EB-2A Special Ear Bar (hollow type, in a pair)
EB-2B Special Ear Bar (non-ruputure type, in a pair)
EB-2C Special Rat Ear Bar (in a pair)
Specification
| Length/Weight | L140mm, 95g (per pair) |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Rat Ear Bar for SR Series
| |
EB-3A:
$232.43
†
- Ships in 1-5 days
|
|
Narishige's EB-3A is a rat ear bar for SR series Stereotaxic Instruments.
Specification | Dimensions/Weight | L70mm, 36g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Mouse Ear Bar for SR Series
| |
EB-3B:
$232.43
†
- Ships in 1-5 days
|
|
Narishige's EB-3B is a mouse Ear Bar for SR series Stereotaxic Instruments.
Specification | Dimensions/Weight | L70mm, 36g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Auxiliary Rat Ear Bar
| |
EB-4N:
$756.76
†
- Ships in 1-5 days
|
|
Narishige's EB-4N is an auxiliary rat ear bar for use with the SR series stereotaxic instruments. It can be attached to the rat before the rat is set on the stereotaxic instrument. The smooth sliding system allows you to feel the delicate holding touch. After use, the EB-4N can be disassembled for cleaning.
Specification
| Dimensions / Weight | W36-53 x D37 x 10mm, 32g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Auxiliary Mouse Ear Bar
| |
EB-5N:
$756.76
†
- Ships in 1-5 days
|
|
Narishige's EB-5N is an auxiliary mouse ear bar for use with the SR series stereotaxic instruments. It can be attached to the mouse before the mouse is set on the stereotaxic instrument. The smooth sliding system allows you to feel the delicate holding touch. After use, the EB-5N can be disassembled for cleaning.
Specification
| Dimensions / Weight | W36-53 x D37 x 10mm, 32g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Auxiliary Mouse Ear Bar
| |
EB-6:
$756.76
†
- Ships in 1-5 days
|
|
Narishige's EB-6 is a more friendly auxiliary mouse ear bar for use with the SR series stereotaxic instruments. The design keeps the eardrum intact and reduces injury to the mouse ear tube. The fixing points are more dull, making it easier to fix the ear tube without puncturing anything or causing bleeding in the ear. The user saves on recovery time due to perforated eardrums and ear tube injuries, and can quickly move on to the next imaging / recording procedure. This non-rupture-point ear bar is also more practical for chronic and awake experiments.
This picture shows the EB-6 attached to the SR-5M-HT sterotaxic frame for mouse research:
Specification
| Dimensions / Weight | W45 ~ 63 x D37 x H12mm, 35g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Gas Masks For Rats
| |
GM-3:
$389.19
†
- Ships in 1-5 days
|
|
Narishige's GM-3 gas masks for rats permits easy installation on the new stereotaxic instrument Models SR-5M, SR-5R, SR-6M, and SR-6R. It is intended for use with anesthesia vaporizers. With the tube connected, these gas masks serve the purpose of administering anesthetics. With the three-point clamping arrangement undisturbed, these gas masks permit the nose clamp and ensure secure fixing. The compact design does not interfere with experimental procedures.
*Consult us if you wish to install these gas masks on such devices as head holding adaptors or old-type stereotaxic instruments.
Specification
tr>| Dimensions/Weight | W22 × D35 × H19mm, 18g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Gas Masks For Mice
| |
GM-4:
$389.19
†
- Ships in 1-5 days
|
|
Narishige's GM-4 gas masks for mice permits easy installation on the new stereotaxic instruments Models SR-5M, SR-5R, SR-6M, and SR-6R. It is intended for use with anesthesia vaporizers. With the tube connected, these gas masks serve the purpose of administering anesthetics. With the three-point clamping arrangement undisturbed, these gas masks permit the nose clamp and ensure secure fixing. The compact design does not interfere with experimental procedures.
*Consult us if you wish to install these gas masks on such devices as head holding adaptors or old-type stereotaxic instruments.
Specification
tr>| Dimensions/Weight | W20 × D28 × H14mm, 10g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Instruments Adapter (for Cats)
| |
IA-9:
$1,621.62
†
- Discontinued
|
|
Narishige's IA-9 adapter is used to tilt a fixed cat's head and is employed with the SN series. It is attached between the head holder and U-frame, and provides a 45 degree tilting angle.
Specification
| Dimensions/Weight | W105 x D45 x H130mm, 700g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Electrode Carrier Stand
| |
MA-2:
$810.81
†
- Ships in 1-5 days
|
|
Narishige's MA-2 is an electrode carrier stand. This stand is for temporary storage of stereotaxic manipulators when not in use. Specially designed to accommodate the manipulators' particular shape, it is a most useful item.
Specification | Dimensions/Weight | W250 x D150 x H85mm, 2kg |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Mouse Head Holding Adaptor
| |
MA-6N:
$1,243.24
†
- Ships in 1-5 days
|
|
Narishige's MA-6N is a mouse head holding adaptor for use with the SR series stereotaxic instruments. The use of the dovetail mechanism achieved by the application of the proven micromanipulator technology permits smooth adjustments. The MA-6N comes equipped with an improved auxiliary ear bar that is easy to attach and allows you to feel the holding touch.
Specification
| Dimensions / Weight | W20 x D98 x H50-70mm, 132g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Adapter for Stereotaxic Instruments (for Guinea Pigs)
| |
RA-3:
$951.35
†
- Special Order
|
|
Narishige's RA-3 is a head holding adapter for use with the SN series with guinea pigs.
The use of the separately available EB-2D special ear bar, makes it usable with a guinea pig.
Specification
| Dimensions/Weight | W145 x D40 x H50mm, 300g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Adapter for Stereotaxic Instruments (for Rabbits)
| |
RA-5:
$1,902.70
†
- Special Order
|
|
Narishige's RA-5 adapter allows for use of the SN series with rabbits. Since an ear bar is not suitable for a rabbit, this fixing instrument holds the rabbit temple instead, completing the fixation with a standard mouthpiece and eye bar.
Specification
| Dimensions/Weight | W200 x D115 x H85mm, 850g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Rat Head Holding Adaptor
| |
RA-6N:
$1,243.24
†
- Ships in 1-5 days
|
|
Narishige's RA-6N adapter is used to convert a mouse fixing clamp to a rat fixing clamp. The dovetail structure permits simple adjustment of the mouth and nose clamp position; the procedure can be smoothly and easily performed with one hand. This is also true of the clamping action using an auxiliary ear bar, which is easier than with conventional models.
Specification
| Dimensions / Weight | W20 x D98 x H50-70mm, 132g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Electrode Position Calibrator
| |
- Special Order - Pricing Available Upon Request
|
|
Narishige's SN-51 allows the gauge mark (0 point) of the SN series Stereotaxic Instrument to be determined with the electrode carrier mounted on the stereotaxic instrument.
Specification
| Dimensions/Weight | W150 x D30 x H100mm, 0.4kg |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Holding Adaptor (for Rats)
| |
SG-3N:
$1,189.19
†
- Special Order
|
|
Narishige's SG-3N and SG-4N mouse/rat head holding devices are capable of use in different variations and offer wide applicability
This simple and compact model is designed for the purpose of fixing the head, with special consideration paid to ease of use on a microscope stage. The clamping method is based on 3-point fixation (mouth, nose and ear), ensuring that the head is easily and firmly fixed in position without damage to even small animals. By attaching the mouth/nose clamp and ear bar to a single bar, the instrument allows the head angle to be freely adjusted through 360. Developed to allow low gravity fixation, the holder's overall size is very compact, making it ideal for fixing a small animal on to a microscope stage. The shape and functions are simple, yet this holder can be used for many different purposes. The SG-3N is for rats, and the SG-4N for mice.
Specification
| Base dimensions | W140-180 x D60 x H50mm | | Weight | 510g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Holding Adaptor (for Mice)
| |
SG-4N:
$1,189.19
†
- Discontinued
|
|
Narishige's SG-3N and SG-4N mouse/rat head holding devices are capable of use in different variations and offer wide applicability
This simple and compact model is designed for the purpose of fixing the head, with special consideration paid to ease of use on a microscope stage. The clamping method is based on 3point fixation (mouth, nose and ear), ensuring that the head is easily and firmly fixed in position without damage to even small animals. By attaching the mouth/nose clamp and ear bar to a single bar, the instrument allows the head angle to be freely adjusted through 360. Developed to allow low gravity fixation, the holder's overall size is very compact, making it ideal for fixing a small animal on to a microscope stage. The shape and functions are simple, yet this holder can be used for many different purposes. The SG-3N is for rats, and the SG-4N for mice.
When used in combination with an optionally available mounting adaptor, the low-center-of-gravity design enables the detachable head clamp unit to be installed on a microscope stage allowing the securely fixed head of a mouse to be observed under a microscope.
Specification
| Base dimensions | W140-180 x D60 x H50mm | | Weight | 510g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Common Marmoset Chair
| |
SH-100:
$6,481.08
†
- Group II Special Order
|
|
Common Marmoset Chair
This chair allows the common marmoset to be placed in position without anesthesia. The device is optimized for training the animal because it has 360-degree access from different directions. By using large knobs on four pillars, every parts of the height and angle adjustment are easily operated. The marmoset can be kept in a natural position by adjusting the tilting angle of the plate around the neck. Transparent acrylic plates allow for the whole body of the animal to be observable. The whole chair can be affixed on a anti-vibration table by using holes on the bottom plate.
* Combine with the accessory SH-100A (sold separately) for a wide range of uses in experiments.
Specification
| Accessories included | Hex Wrench
Tray
Footrest pipe × 7 | | Dimensions/Weight | W307 x D350 x H400mm, 5.7kg |
|---|
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stage with AP Frame Bars fro SH-100
| |
SH-100A:
$4,518.92
†
- Group II Special Order
|
|
Stage with AP Frame Bars for SH-100
This is an optional product for the common marmoset chair SH-100 which is able to attach a stereotaxic micromanipulator. The stage is adaptable for use with a wide variety of experiments because it has two AP frame bars. Once a marmoset is fixed in position with stereotaxic instruments (SR-5C-HT), it is applicable for a chronic experiment by gluing pipes for the head fixation (SH-100B) which can be operated by using a holder for the head fixation pipe (SH-100C).
* When it is positioned 20mm or less in the area where partially affixing the neck to the lower part of SH-100 as opposed to the top side of pipe, it is fixable. However, when it is in the higher position than 20mm, it is not possible to fix.
Specifications
| Accessories included | Hex Wrench
SH-100B × 2
Guide pipe × 2 | | Dimensions/Weight | W290 x D240 x H60mm, 3.2kg |
|---|
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Fixing Pipes for SH-100
| |
SH-100B:
$261.62
†
- Special Order
|
|
Head Fixing Pipes for the Common Marmoset
This is a pipe used to glue on the head of a common marmoset and affix the head. After a marmoset is fixed in position with stereotaxic instruments (SR-5C-HT), two pipes can be glued in position by using the holder SH-100C. Resin or dental cement is required for gluing and sold separately. (Not available through Tritech.)
* Sold per pack of 6 pieces
Specifications
| Dimensions/Weight | W6.5 x D6.5 x H20mm, 0.5g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Holder for Head Fixing Pipes (SH-100B)
| |
SH-100C:
$392.43
†
- Special Order
|
|
Holder for gluing SH-100B Head Fixing Pipes for the Common Marmoset
This is a holder for gluing SH-100B pipes onto the head of common marmosets. The holder diameter is 8mm O.D., and it can be mounted to the SMM series (SMM-100).
* When the SH-100C is attached to the SM-15, SM-15A is required (sold separately)
Specifications
| Accessories included | Hex Wrench
Set Screw x 2 | | Dimensions/Weight | W6.5 x D6.5 x H20mm, 0.5g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Non-Traumatic Head Holder (for Cats)
| |
SH-14:
$755.68
†
- Special Order
|
|
Narishige's SH-14 holder fixes a cat's head simply with a clamp attached to the tip of the 12mm bar. It can be set to a magnetic stand for use in combination with the X-block.
*Use GJ-8 magnetic stand or equivalent equipment to attach this model.
Specification
| Dimensions/Weight | W190 x D48 x H45mm, 250g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Non-Traumatic Head Holder (for Guinea Pigs)
| |
SH-15:
$1,070.27
†
- Discontinued
|
|
Narishige's SH-15 holder fixes a guinea pig's head simply with a clamp attached to the tip of the 12mm bar. An auxiliary fixing knob is incorporated as well, making the fix more stable. The holder can be set to a magnetic stand for use in combination with the X-block.
*Use GJ-8 magnetic stand or equivalent equipment to attach this model.
Specification
| Dimensions/Weight | W200 x D23 x H45mm, 300g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Non-Traumatic Head Holder (for Cats)
| |
SH-16:
$1,278.92
†
- Special Order
|
|
Narishige's SH-16 holder fixes a cat's head simply with a clamp attached to the tip of the 12mm bar. A nose fixing knob is incorporated as well, making the fix more stable. The holder can be set to a magnetic stand for use in combination with the X-block.
*Use GJ-8 magnetic stand or equivalent equipment to attach this model.
Specification
| Dimensions/Weight | W245 x D42 x H57mm, 350g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Non-Traumatic Head Holder (for Rats)
| |
SH-8:
$755.68
†
- Special Order
|
|
Narishige's SH-8 holder fixes a rat's head simply with a clamp attached to the tip of the 12mm bar. It can be set to a magnetic stand for use in combination with the X-block.
*Use GJ-8 magnetic stand or equivalent equipment to attach this model.
Specification
| Dimensions/Weight | W170 x D40 x H40mm, 200g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Cannula Holder for SM-15
| |
SHC-1:
$324.32
†
- Ships in 1-5 days
|
|
Narishige's SHC-1 holder allows accurate, safe, and quick placement of a cannula of approx.3.5mm in lab animals. Using a stereotaxic instrument and the SM-15 micromanipulator, a cannula can be placed at a specific site safely and accurately. The cannula can be fixed firmly in place just by tightening the screw and easily removed when in place just by loosening the screw. In addition, the tip is plastic so it will not corrode.
SPECIFICATION
| Dimensions/Weight | ø5 × L150mm, 29g |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Manipulator
| |
SM-12:
$1,351.35
†
- Ships in 1-5 days
|
|
Narishige's SM-12 is very simple, economical manipulator for stereotaxic instruments and can be mounted by various methods. A coarse movement unit is provided for the most important movement (vertical), while position adjustment for the others can be done with sliders. Rotation mechanisms are employed for the vertical and horizontal directions, enabling easy approach from any required tilting angle.
Specification
| Accessories included | Screw
Allen Wrench |
|---|
| Movement range | Coarse | Z65mm |
|---|
| Dimensions/Weight | W140 × D47 × H220mm, 900g |
|---|
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Multielectrode Holder for SM-12
| |
SM-12P:
$101.62
†
- Special Order
|
|
Narishige's SM-12P is a multielectrode holder for use with the SM-12 Stereotaxic Micromanipulator. This holder enables simultaneous insertion of a maximum of 12 electrodes for recording or stimulating.
*SM-12 sold separately
Specification
| Height/Weight | H120mm, 80g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Attachment for SM-15
| |
SM-15C:
$210.81
†
- Ships in 5-7 days
|
|
SM-15C is the attachment for SMM Series to use with SM-15 products such as SD-101 and SHC-1 (5mm O.D. shaft).
Specifications
| Accessory included | Hex Wrench |
|---|
| Dimensions/Weight | W38 × D13 × H12mm, 24g |
|---|
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Substage for SM-15
| |
SM-15M:
$681.08
†
- Discontinued
|
|
Narishige's SM-15M adds Y-axis movement to the SM-15. The standard SM-15 has X- and Z-axis movement units, but no Y-axis movement (i.e. the same direction as the AP frame bar). This one-axis fine movement unit can therefore be placed between the AP frame bar attachment point and the SM-15 body. This enables smoother, more precise adjustment than was possible by the former method of adjusting the Y-axis with the sliding AP frame bar.
Specification
| Accessory included | Allen Wrench |
|---|
| Movement range | Fine | 20mm
Full rotation of knob: 500µm
Minimum graduation: 10µm |
|---|
| Dimensions/Weight | W81 × D38 × H39mm, 520g |
|---|
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Multielectrode Holder for SM-15
| |
SM-15P:
$101.62
†
- Special Order
|
|
Narishige's SM-15P provides for simultaneous insertion of multiple microelectrodes into a living organism. This multi-electrode holder is attached to the SM-15 for use, replacing the standard SM-15 holder. It allows up to 12 microelectrodes to be arranged in a line, so that several can be inserted into a living organism for simultaneous stimulation and recording of many areas.
Specification
| Height/Weight | H145mm, 50g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
SM-20 Electrode Holders (For Three Electrodes)
| |
SM-17:
$1,486.49
†
- Special Order
|
|
Narishige's SM-17 holder for three microelectrodes is developed for the SM-20 . It allows three microelectrodes to be placed in adjacent positions, and also features a coarse and fine movement unit in the Z-axis. Can also be used with the SM-21 .
Specification
| Accessory | Dedicated electrode holders | | Movement range | Coarse | Z40mm | | Fine | Z7mm
Full rotation of knob 250um
Minimum graduation 10um | | Dimensions/Weight | W107 x D185 x H100mm, 680g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
SM-20 Electrode Holders (For One Electrode)
| |
SM-19:
$951.35
†
- Special Order
|
|
Narishige's SM-19 multi-microelectrode holder is incorporated to the SM-20 . Mounting coarse and fine movement units in the Z-axis enables a wide range of possible uses. Can also be used with the SM-21 .
Specification
| Accessory | H-1 Electrode holder | | Movement range | Coarse | Z40mm | | Fine | Z7mm
Full rotation of knob 250um
Minimum graduation 10um | | Dimensions/Weight | W45 x D170 x H100mm, 400g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Attachment for SMM series to affix syringe or holder
| |
SMM-A:
$410.81
†
- Ships in 5-10 days
|
|
Attachment for SMM series to affix syringe or injection holder.
This attachment is intended to hold and move an additional tool with a shaft with 8mm O.D. With this attachment, a micromanipulator from the SMM series can hold two holders at a time. The attachment is affixed with screws in the screw holes on the side of X-axis unit of the SMM series; then the additional tool can be slid its position one end to the other. When a tool from the SMM series is tilted or used with IMS-20, this attachment helps to position the tip of the holder and keeps it from situating beyond the median line.
The setting example of adding IMS-20 to SMM-A
Holders for SMM Series
| Model | SMM-A | SMM-HA | SMM-HB | SMM-HC | SMM-HD | | Description | Attachment | Holder for Neural Probes | Holder for Neural Probes | Cannula Holder | Multiuse Holder | Specifications
| Accessories included | Hex Wrench
Mounting Knob × 2 | | Dimensions/Weight | W72 × D12 × H20mm, 62g |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Holder for using silicon neural probes with SMM series
| |
SMM-HA:
$356.76
†
- Ships in 5-10 days
|
|
Holder for Neural Probes
Holder made for using silicon probes with SMM series products
This holder is intended to hold a silicon probe on SMM series products. The silicon probe can be affixed close to the holder shaft to prevent interference around the probe. The holding section is made with resin - thus it does not conduct electricity when in contact with a substrate. (The photograph above shows the holding of a silicon probe by NeuroNexus.)
Holders for SMM Series
| Model | SMM-A | SMM-HA | SMM-HB | SMM-HC | SMM-HD | | Description | Attachment | Holder for Neural Probes | Holder for Neural Probes | Cannula Holder | Multiuse Holder | Specification
| Accessories included | Hex Wrench
Fixing Knob
Set Screw × 2 | | Dimensions/Weight | W13 × D12 × H222mm, 90g | | Applicable silicon probes | Thickness: 2mm or less
Width: within 2.5 ~ 5mm
Length: 12mm or longer |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Holder for using silicon neural probes with SMM series
| |
SMM-HB:
$356.76
†
- Ships in 5-10 days
|
|
SMM-HB Holder for Neural Probes
Holder made for using silicon probes with SMM series
This holder is intended to hold a silicon probe on SMM series products. A silicon probe can be affixed with greater distance away from the holder shaft when it is necessary (compared to the SMM-HA that is affixed very close to the shaft.) The holding block is made with resin - thus it does not conduct electricity when in contact with a substrate. The holding section can be detached from the shaft and reversed in orientation (Left-right). (The photograph above shows the holding of a silicon probe by NeuroNexus.)
Holders for SMM Series
| Model | SMM-A | SMM-HA | SMM-HB | SMM-HC | SMM-HD | | Description | Attachment | Holder for Neural Probes | Holder for Neural Probes | Cannula Holder | Multiuse Holder | Specification
| Accessories included | Hex Wrench
Fixing Knob
Set Screw × 2 | | Dimensions/Weight | W28 × D8 × H212mm, 85g | | Applicable silicon probes | Thickness: 2mm or less
Width: within 2.5 ~ 5mm
Length: 12mm or longer |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Cannula holder for SMM series
| |
SMM-HC:
$356.76
†
- Ships in 5-10 days
|
|
Cannula Holder for SMM series
This holder is intended to hold a cannula within 3.4mm and 3.5mm O.D. on SMM series. The upper tip of the cannula is visible when affixed - thus it is easy to confirm proper insertion of the cannula. The holding section can be detached from the shaft and changed in orientation (Left-right). Comparatively to SHC-1, the products differ in the diameter of the shaft and the way the cannula is held. (SMM-HC has the shaft with 8mm O.D., and the cannula won't be affixed from the top without covering the upper side of cannula - thus a T-shaped cannula can be affixed as well).
The above photo shows the setting example for SR-5M-HT+ SM-100 + SMM-HC.
Setting example of T-shaped cannula
Holders for SMM Series
Specifications
| Dimensions/Weight | W29 × D8 × H206mm, 90g |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Multiuse holder for SMM series to affix syringe or injector
| |
SMM-HD:
$410.81
†
- Ships in 5-10 days
|
|
Multiuse holder for SMM series to affix a syringe or injection holder
This holder is intended to hold instruments measuring between 4mm O.D. to 10mm O.D., which allows for the MO-10 and MO-82 to be affixed at a low-reach position on SMM series products without using a long holder. The HI-7 and HI-9 microinjection holders (4mm O.D.) and a glass syringe (10mm O.D. or less) can be affixed directly onto this holder as well. The holding section can be detached from the shaft and changed in orientation (Left-right). The above photo illustrates a setting example of the SR-5M-HT + SMM-100 + SMM-HD + MO-10.
Holders for SMM Series
Specifications
| Accessory included | Hex Wrench | | Dimensions/Weight | W48 × D15 × H225mm, 143g |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Auxilary Fixing Stand for SN-2/SN-3
| |
- Special Order - Pricing Available Upon Request
|
|
Narishige's SP-M pole is used to attach a 12mm bar mounting micromanipulator to the base of an SN-2 or SN-3 stereotaxic instrument.
Specification
| Height/Weight | H375mm, 4.5kg |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Plate For Attachment of Parts in the SR Series
| |
SR-A:
$778.38
†
- Ships in 1-5 days
|
|
The * The plate is customizable for your application.
SR-A Plate is meant for attachment of parts in the SR series like ear bars (EB-3A, EB-3B), auxiliary ear bars (EB-4N, EB-5N), and mouth/nose clamp .
Specification
| Dimension, Weight | W300 x D120 x H86mm, 1kg |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Holding Device (for Common Marmosets) converting SR series.
| |
SR-AC:
$3,189.19
†
- Ships in 1-5 days
|
|
The SR-AC head holding device can be attached to the SR series and make your stereotaxic instrument usable for common marmosets.
Specification
| Accessories | EB-3A Ear Bars
Dedicated Auxiliary Ear Bar
Hex Wrench | | Dimension, Weight | W300 x D200 x H98mm, 1.3kg |
* The anesthetic mask (GM-3/GM-4) cannot be attached to this head holder.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Holding Device (for Mice) converting SR Series
| |
SR-AM:
$2,216.22
†
- Ships in 1-5 days
|
|
Converting your stereotaxic instrument to a head holding device for mice.
The SR-AM head holding device can be attached to the base plate of SR series. Your stereotaxic instrument can be converted to an instrument for mice.
Specification
| Accessories | EB-3B Ear Bars
EB-5N Auxiliary Ear Bar
Hex Wrench
Mounting Knob | | Dimension, Weight | W300 x D190 x H88mm, 1.2kg |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Holding Device (for Rats) converting SR Series
| |
SR-AR:
$2,216.22
†
- Ships in 1-5 days
|
|
Converting your stereotaxic instrument to a head holding device for rats.
The SR-AM head holding device can be attached to the base plate of SR series. Your stereotaxic instrument can be converted to an instrument for rats.
Specification
| Accessories | EB-3A Ear Bars
EB-4N Auxiliary Ear Bar
Hex Wrench
Mounting Knob | | Dimension, Weight | W300 x D190 x H88mm, 1.2kg |
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Micromanipulator Fixing Attachment
| |
Y-1:
$713.51
†
- Special Order
|
|
Narishige's Y-1 adapter is used to mount a micromanipulator fixed to a bar, such as the MM-3, to the AP frame bar of a stereotaxic instrument.
Specification
| Dimensions/Weight | W90 x D40 x H140mm, 750g |
*This is a Narishige "Group-2" special order item. Because it has to be custom-made for you, there is usually a 4-week lead time and it is non-cancellable and non-returnable once ordered. Prices for Group-2 items change often, and, like all of our website prices are subject to change without notice, so always double-check with us prior to placing an order for this item.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Holding Adaptor for Common Marmosets
| |
CA-6:
$2,216.22
†
- Ships in 1-5 days
|
|
This adaptor allows existing SR-series stereotaxic instruments for rats or mice to be used with marmosets. A dovetail is employed in the mouthpiece and eye-bars. It moves so smoothly to allow position adjustment with one hand.
Specifications:
Dimensions/Weight: W125 D52 H67mm, 0.22kg
Accessory included: Auxiliary Ear Bar
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Simple Head Holder Plate (for Mice)
| |
MAG-1:
$562.16
†
- Ships in 5-7 Days
|
|
* Attachable chambers: CF-10, CP, CP-1, CP-2
For observations of a mouse under a microscope.
After bonding a chamber onto the head of a mouse (for example using temporary or permanent dental cement) on the SR-9M-HT Stereotaxic Instrument, the chamber can be transferred to the MAG-1 and placed under a microscope or other instrument for performing observations and experiments. Designed to be compact in size, the MAG-1 can be placed under a two-photon microscope or stereomicroscope.
In the photo shown, the two silver colored bars are actually the two long sides of the rectangular CF-10 stainless steel frame.
Specifications: | Accessories included | CF-10 Chamber Frame (1 pcs | | Dimensions/Weight | W96 x D84 x H42mm, Approx. 102g | * The chamber frame is customizable to your own application. Please contact us for details. * The CFR-1 Chamber Frame (for rats) can NOT be attached.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Holding Device (with Angle Adjuster / for Mice)
| |
MAG-2:
$4,648.65
†
- Ships in 5-7 Days
|
|
* Attachable chambers: CF-10, CP, CP-1, CP-2
For observations of a mouse under a microscope.
After bonding a chamber onto the head of a mouse on the SR-9M-HT Stereotaxic Instrument, the MAG2, designed to be compact in size, can be transferred and placed under a microscope or other experimental instrument for performing observations/experiments.
The MAG-2 can be placed under a laser microscope or stereomicroscope, and is most suitable for in vivo observation/imaging experiments. It is equipped with angle adjusters for obtaining deeper images.
In the photo, MAG-2 is shown holding a CP-1 mounting plate (that is sometimes attached to the animal with temporary or permanent dental cement).
Setting Example:  Angle of Inclination  Longitudinal inclination (± 10°)  Lateral inclination (± 15°) Specifications: | Accessories included | CP-1 Chamber Plate (one each)
CP-2 Chamber Plate (one each)
Hex Wrench
Vinyl Sheet | | Dimensions/Weight | W87 x D136 x H58 ~ 72mm, 232g | | Maximum angle of inclination | Longitudinal | ± 10° | | Lateral | ± 15° | Load-bearing Capacity | 0.5kg | * The chamber frame is customizable to your own application. Please contact us for details. * The CFR-1 Chamber Frame (for rats) can NOT be attached.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Head Holding Device (with Angle Adjuster / for Mice)
| |
MAG-3:
$5,189.19
†
- Ships in 5-7 Days
|
|
* Attachable chambers: CF-10, CP, CP-1, CP-2
For observations of a mouse under a microscope.
The MAG3 can be transferred and placed under a microscope or other experimental instrument for performing to observe and experiment on mice, after attaching a chamber onto the head of a mouse on the SR-9M-HT Stereotaxic Instrument, .
The MAG-3 can be placed under a stereomicroscope, and is most suitable for in vivo observation/imaging experiments. It is equipped with angle adjusters for obtaining deeper images. It is slightly bigger than the MAG-2 but can be inclined at a steeper angle which is useful for making an approach to the temporal region of the head.
In the photo, MAG-3 is shown holding a CP-1 mounting plate (that is sometimes attached to the animal with temporary or permanent dental cement).
Angle of Inclination Longitudinal inclination (± 10°)  Lateral inclination (± 15°) Specifications: | Accessories included | CP-1 Chamber Plate (one each)
CP-2 Chamber Plate (one each)
Vinyl Sheet | | Dimensions/Weight | W108 x D152 x H109 ~ 130mm, 1.7Kg | | Maximum angle of inclination | Longitudinal | ± 15° | | Lateral | ± 20° | Load-bearing Capacity | 2kg | * The chamber frame is customizable to your own application. Please contact us for details. * The CFR-1 Chamber Frame (for rats) can NOT be attached.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Simple Head Holder Plate (for Mice)
| |
MAG-A:
$540.54
†
- Ships in 5-7 Days
|
|
Used for behavior imaging/electrophysiology recording with awake mice. The MAG-A can be used with MAG-1, MAG-2 or MAG-3. It keeps the head in position of awake mice. Chamber frame or plate applied on the animal will be fixed firmly by screws from two sides, which is suitable for behavior imaging and electrophysiology recording experiments of awake mice.
Setting Example
MAG-1 with CF-10:
MAG-2 with CP-1:
MAG-3 with CP-2:
Specifications: | Dimensions/Weight | W60 × D15 × H6mm, 20g | * The CFR-1 / CFR-2 Chamber Frame (for rats) cannot be used with the MAG-A.
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Micromanipulator
| |
SM-11:
$4,216.22
†
- Special Order
|
|
Narishige's SM-11 is the most popular (and versatile) micromanipulator for stereotaxic instruments because it can be attached to any of our AP frame bars and provides multi-axis movement. A coarse movement unit with a long working range is attached to the Z-axis, in addition to the fine movement adjustments included for each individual axis. These fine movement units have scales with minimum increments of 10µm (i.e. the total of a single rotation, 500µm, divided into 50 gradations), so that precise adjustments of 10µm are possible. In addition, the Z-axis fine movement unit has a sliding mechanism that enables approximate positioning of the X-axis. A rotation mechanism is provided for each of the X-Y, X-Z and Y-Z planes that allows approach from any required angle. Easy-to-use scales are provided wherever necessary, permitting for operations following a brain chart. Overall, this micromanipulator is simple to use and meets a wide variety of applications.
Specifications:
| Accessories included | Dedicated Electrode Holder (for ±1mm)
Trim Screw |
|---|
| Movement range | Coarse | Z60mm |
|---|
| Fine | X30mm, Y30mm, Z30mm
Full rotation of knob: 500µm
Minimum graduation: 10µm |
|---|
| Dimensions/Weight | W150 × D104 × H225mm, 1.75kg |
|---|
|
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Micromanipulator
| |
SMM-100:
$4,702.70
†
- Ships in 1-5 days
|
|
The SMM-100 Stereotaxic Micromanipulator is made for use in animal experiments utilizing traditional methods of acute/chronic experiments or electro-physiological recording, as well as for newly developed methods of multi-photostimulations and silicon probes. SMM-100 is equipped with a Y-axis control knob which makes the fine adjustment in the AP direction possible. The upper body of SMM-100 is switchable in either AP or ML direction when using it with tilting angle.
SMM-100 + DMA-1511 setting example
SMM Series Comparison Table
| SMM Series | SMM-100 | SMM-200 | SMM-100B | SMM-200B | | Angles | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | | Fine Y-axis | Installed | Installed | Not installed | Not installed | Holders for SMM series
Specification
| Accessories included | Hex Wrenches (2mm and 2.5mm)
Dedicated electrode holder (with attachment and screw)
Screw for grounding
Washers for grounding (Bellville washer and flat washer) | | Movement range | X80mm, Y20mm, Z80mm
Full rotation of knob 1mm
Minimum graduation 10µm | | Dimensions/Weight | W85 × D162 × H256mm, 1.84kg |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Micromanipulator
| |
SMM-100B:
$4,108.11
†
- Ships in 1-5 days
|
|
The SMM-100B Stereotaxic Micromanipulator is made for use in animal experiments using traditional methods of acute/chronic experiments or electro-physiological recording, as well as for newly developed methods of multi-photostimulations and silicon probes. It is designed without a Y-axis control knob so that two or more micromanipulators can be set close together. The upper body of SMM-100B is switchable in either AP or ML directions when using it with tilting angle.
SMM Series Comparison Table
| SMM Series | SMM-100 | SMM-200 | SMM-100B | SMM-200B | | Angles | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | | Fine Y-axis | Installed | Installed | Not installed | Not installed |
Holders for SMM series
Specification
| Accessories included | Hex Wrenches (2mm and 2.5mm)
Dedicated electrode holder (with attachment and screw)
Screw for grounding
Washers for grounding (Bellville washer and flat washer) | | Movement range | X80mm, Z80mm
Full rotation of knob 1mm
Minimum graduation 10µm | | Dimensions/Weight | W49 × D162 × H241mm, 1.56kg |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Micromanipulator
| |
SMM-100C:
$4,702.70
†
- Ships in 1-5 days
|
|
The SMM-100C is a new coarse manipulator for stereotaxic instruments focusing on driving outside the animal's brain. The driving by Z-axis control knob: approximately 4mm per rotation makes faster adjustments for leveling bregma and lambda, and faster retracting/returning from the dura mater, which will improve efficiency of the experiment. For operations inside the brain, One-axis Motorized Stereotaxic Micromanipulator MDS-1 and hydraulic manipulator can be added optionally. The X-axis is equipped with a coarse control knob, which is the same as the Z-axis. The Y-axis (anterior/ posterior direction) is equipped with a fine control knob. The upper body of SMM-100C is switchable in either AP or ML direction when using it with tilting angle.
* The minimum graduation of the X and Z-axis is 100µm. This manipulator is recommended to be used in combination with a fine micromanipulator (MDS-1, etc).
Set-up example
*Stereotaxic instrument, GM-4, MDS-1, and SMM-HA, the silicon probe in the photo above are not included.
Set-up example with SMM-A
SMM-A is recommended for experiments: tilting in the ML direction.
When the manipulator SMM-100C/200C is tilted in the ML direction, the end of the holder (electrode tip) may be far off from animal's head. The attachment SMM-A is designed to attach a holder on the side of manipulator, so it enables the holder position without operating the X-axis. To this end, the holder (electrode tip) can be set to the animal's head while maintaining driving distance of the X-axis.
*The set-up example above: motorized MDS-1 and IMS-30 on SMM-100C installed with SMM-A.
SMM Series Comparison Table
| SMM Series | SMM-100 | SMM-200 | SMM-100C | SMM-200C | | Angles | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | | X Axis, Z-axis | Fine | Fine | Coarse | Coarse |
|---|
Y-axis | Fine | Fine | Fine | Fine | Holders for SMM series
Specification
| Accessories included | Hex Wrenches (2mm and 2.5mm)
Dedicated electrode holder (with attachment and screw)
Screw for grounding
Washers for grounding (Bellville washer and flat washer) | | Movement range | X80mm, Z80mm
Full rotation of knob 4.2mm
Minimum graduation 100µm(Vernier scale)
Y20mm, Full rotation of knob 1mm,
Minimum graduation 10µm | | Dimensions/Weight | W85 × D162 × H256mm, 1.75kg |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Micromanipulator
| |
SMM-200:
$5,405.41
†
- Ships in 5-10 days
|
|
Simultaneous Dual Angles: AP and ML directions
The SMM-200 Stereotaxic Micromanipulator is made for use in animal experiments with traditional methods of acute/chronic experiments or electro-physiological recording, as well as for newly developed methods of multi-photostimulations and silicon probes. The SMM-200 is equipped with a Y-axis control knob which makes the fine adjustment in the AP direction possible. The upper body of SMM-200 can be tilted with dual angles: AP and ML directions simultaneously.
Drill installed on SMM-200
* When the compact drill for Stereotaxic Instruments, SD-101 is installed with the SMM series, SM-15C attachment is required (sold separately).
SMM Series Comparison Table
| SMM Series | SMM-100 | SMM-200 | SMM-100B | SMM-200B | | Angles | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | | Fine Y-axis | Installed | Installed | Not installed | Not installed | Holders for SMM series
Specification
| Accessories included | Hex Wrenches (2mm and 2.5mm)
Dedicated electrode holder (with attachment and screw)
Screw for grounding
Washers for grounding (Bellville washer and flat washer) | | Movement range | X80mm, Y20mm, Z80mm
Full rotation of knob 1mm
Minimum graduation 10µm | | Dimensions/Weight | W85 × D162 × H286mm, 2.09kg |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Micromanipulator
| |
SMM-200B:
$5,405.41
†
- Ships in 5-10 days
|
|
The SMM-200B Stereotaxic Micromanipulator is made for use in animal experiments with traditional methods of acute/chronic experiments or electro-physiological recording, as well as for newly developed methods of multi-photostimulations and silicon probes. It is designed without a Y-axis control knob so that two or more micromanipulators can be set close together. The upper body of SMM-200B can be tilted with dual angles: AP and ML directions simultaneously.
SMM Series Comparison Table
| SMM Series | SMM-100 | SMM-200 | SMM-100B | SMM-200B | | Angles | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | | Fine Y-axis | Installed | Installed | Not installed | Not installed |
Holders for SMM series
Specification
| Accessories included | Hex Wrenches (2mm and 2.5mm)
Dedicated electrode holder (with attachment and screw)
Screw for grounding
Washers for grounding (Bellville washer and flat washer) | | Movement range | X80mm, Z80mm
Full rotation of knob 1mm
Minimum graduation 10µm | | Dimensions/Weight | W49 × D162 × H271mm, 1.77kg |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
Stereotaxic Micromanipulator
| |
SMM-200C:
$5,405.41
†
- Ships in 5-10 days
|
|
The SMM-200C is a new coarse manipulator for stereotaxic instruments focusing on driving outside the animal's brain. The driving by Z-axis control knob: approximately 4mm per rotation makes faster adjustments for leveling bregma and lambda, and faster retracting/returning from the dura mater, which will improve efficiency of the experiment. For operations inside the brain, One-axis Motorized Stereotaxic Micromanipulator MDS-1 and hydraulic manipulator can be added optionally. The X-axis is equipped with a coarse control knob, which is the same as the Z-axis. The Y-axis (anterior/ posterior direction) is equipped with a fine control knob. The upper body of SMM-200C can be tilted with dual angles: AP and ML directions simultaneously.
* The minimum graduation of the X and Z-axis is 100µm. This manipulator is recommended to be used in combination with a fine micromanipulator (MDS-1, etc).
Set-up example
*Stereotaxic instrument, GM-4, MDS-1, and SMM-HA, the silicon probe in the photo above are not included.
Set-up example with SMM-A
SMM-A is recommended for experiments: tilting in the ML direction.
When the manipulator SMM-100C/200C is tilted in the ML direction, the end of the holder (electrode tip) may be far off from animal's head. The attachment SMM-A is designed to attach a holder on the side of manipulator, so it enables the holder position without operating the X-axis. To this end, the holder (electrode tip) can be set to the animal's head while maintaining driving distance of the X-axis.
*The set-up example above: motorized MDS-1 and IMS-30 on SMM-200C installed with SMM-A.
SMM Series Comparison Table
| SMM Series | SMM-100 | SMM-200 | SMM-100C | SMM-200C | | Angles | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | One direction
(AP or ML)
Switchable | Simultaneous
Two directions
(AP & ML) | | X Axis, Z-axis | Fine | Fine | Coarse | Coarse |
|---|
Y-axis | Fine | Fine | Fine | Fine | Holders for SMM series
Specification
| Accessories included | Hex Wrenches (2mm and 2.5mm)
Dedicated electrode holder (with attachment and screw)
Screw for grounding
Washers for grounding (Bellville washer and flat washer) | | Movement range | X80mm, Z80mm
Full rotation of knob 4.2mm
Minimum graduation 100µm(Vernier scale)
Y20mm, Full rotation of knob 1mm,
Minimum graduation 10µm | | Dimensions/Weight | W85 × D162 × H286mm, 2.0kg |
†
These are our list prices. If you are paying with an Institutional
Purchase Order or by check, you qualify for a 7.5% discount. Click
here
to change your payment method and see the lower prices.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
| |
